Large Size Butt Fusion Machine

Large Size Butt Fusion Machine

Large size butt fusion machine adopts hydraulic drive to realize the automatic opening and closing of clamp, hydraulic locking system, smart design facer, self-jump heater and remote operation box. All these guarantee safe and easy operation during the construction. This butt fusion welding machine is equipped with crane to lift up the heater and hydraulic unit together with the base machine. The heater coated with Teflon can guarantee high-quality fusion. Our large size butt fusion machines possess temperature controller on operation panel which can control the temperature precisely. Storage shelf with wheels makes it easy to move the heater. This type of butt fusion welding machine has a good price ratio. Stable working performance in overseas construction helps us win more trust from our customers.

1. With large size butt fusion machine, all the welding processes are programmed in the controlling center.
2. All the operation steps of our butt fusion welding machines are recorded in the controlling center.
3. The operator only needs to input the pipe diameter, SDR, material grade. The controlling center will guide him or her for each step and automatically supply the pressure in different welding phases. The whole welding process can be finished and recorded correspondingly.
4. Our large size butt fusion machines are put into mass production around 20 years.

Technical Parameters of Large Size Butt Fusion Welding Machine:

FM-800 FM-1000 FM-1200
Pipe Range Φ800-Φ630 Φ1000-Φ710 Φ1200-Φ710
Power Supply 3-Phase 220V or 380V 3-Phase 220V or 380V 3-Phase 220V or 380V
Heater Power 12 KW 10 KW 13.6 KW
Hydraulic Power 2.2 KW 2.2 KW 2.2 KW
Total Power 14.2 KW 12.2 KW 15.8 KW
Environ. Temp. -10°C to 45°C -10°C to 45°C -10°C to 45°C
Heater Temp. Rise 20 to 30 min 20 to 30 min 20 to 30 min
Pressure Range 0 to 8 Mpa 0to 8 Mpa 0to 8 Mpa
Hydraulic Surface 5026 mm2 6485 mm2 6485 mm2

More Butt Fusion Welding Machines:
1. Automatic Butt Fusion Machine
2. Hydraulic Butt Fusion Machine
3. Manual Butt Fusion Machine
4. CNC Butt Fusion Welding Machine
5. HDPE Butt Fusion Machine
6. Angle Fusion Machine
7. Socket Fusion Machine

Jilin Songjiang Smart Joint Co., Ltd is a professional manufacturer and supplier of large size butt fusion machines in China. In addition to this butt fusion welding machine, we also produce pipe fittings for customers, such as electrofusion fittings, butt fusion fittings, PE transitional fittings, irrigation fittings, stub flange fittings, and so on. With high quality assurance, our butt fusion welding machines are exported to Algeria, UAE, Egypt, Australia, Brazil, Poland, Denmark, Germany, Canada, Libya, Malaysia, the United States, Turkey, New Zealand, Iran, Israel, Chile, Japan, etc.
